Press Enter or right-click and select Done to place the component with the selected iMates.Īdditional options for resolving iMates during placement are available.If additional matches are possible, the component is constrained with the accepted match and previews the next match.If no additional matches are possible, the component is placed and the next instance of the component is previewed.When placing a component with iMates, click the mouse to accept the iMate pair previewed on the graphics window.In the Open dialog box, select either Interactively place with iMates or Automatically generate iMates on place, and then click Open. Browse to a component with one or more defined iMate constraints, and then select it. On the ribbon, click Assemble tab Component panel Place.Open an assembly file that contains one or more components with iMates.It does not mean that all iMate definitions on the component are matched. If the component has multiple iMate definitions, the component loses its transparency after the first iMate result is accepted. Accept the iMate result to place the component. When the component is first previewed, it is transparent, to indicate that it is not yet placed in the assembly. You can accept or discard solutions as needed. When placing a component using iMates, use the preview mode to cycle through iMates on the component and on the target component.
